| BT30 pull stud | Stud without inner hole. Interacts with the size of the shank MAS 403 BT-30. Made of metal. The dimensions of the screw: thread size M12, angle for gripping A = 45 g., Total length L = 43.0 mm, working length L1 = 23.0 mm, maximum outer diameter from 16 to 16.5 mm. Required for fixing a collet chuck in the spindle of a CNC milling machine. |
| BT40 pull stud | Stud with inner hole. Interacts with standard size shank MAS 403 BT, DIN69871. Made of metal. Shaft dimensions: thread size M16, angle to grip A = 45 g., Total length L = 57.0 mm, working length L1 = 32.0 mm, maximum outer diameter from 23 to 23.5 mm, diameter of the inner hole 4 mm . Required for fixing a collet chuck in the spindle of a CNC milling machine. |
